COOLER-ENIX 240
- With CPU temperature color display
- 18 kinds of magic light effect changes (Can be customized)
- Three-phase non-inductive motor (quiet, low-torque starting)
- Ceramic shaft core (strong wear-resistant, cooling pump long running guarantee)
- PPS water parts (high temperature resistance, less deformation, not easy to produce water leakage)
- High and low temperature resistant sealing material (ensure no leakage)
- Low noise (quiet product operation, no noise to disturb consumers)
- Separate blade patented design (unique design for water cooling industry)
- Product overall low evaporation rate (product liquid life assurance)
- High and low temperature rubber pipe (product liquid life guarantee)
- Patented runner – low flow resistance design (water cooling industry unique design, the first use of rubberless shunt design)
- High ratio of filling space (high filling rate, product life guarantee)
- Low thermal resistance heat dissipation performance guarantee (reflecting the overall thermal performance of the product)
- Intel, AMD universal installation backplane bracket installation (easy for consumers to replace the platform)
- High thermal conductivity pure copper contact CPU (ensure fast heat transfer speed)
| No. | Items | Specifications/Conditions |
| 1 | Product model number | BITSYNC 240mm Liquid cooler |
| 2 | Coldplate head size | W70 * L70* H54mm |
| 3 | Coldplate head size | W22.4 X L15.8X H8.5mm |
| 4 | 120 radiator | 276 X 120 X27mm |
| 5 | Hose Specifications | Black rubber pipe *2, coat black braided mesh,L350mm |
| 6 | Hose cover | Aluminum alloy, oxidized black sleeve, ∅12.4*∅13.2*12.3mm |
| 7 | Top cover specifications | 70 x 70 x 41.1mm, made of PC, sprayed black paint onthe surface |
| 8 | Skive base spec | L62*W53*H3.8mm, material copper |
| 9 | Impeller poles | 10 Poles / 10 Poles |
| 10 | Stator slots | 12 slots / 12 slots |
| 11 | Pump rated voltage | DC 12V |
| 12 | Pump starting voltage | >DC 6V |
| 13 | Pump current rating | 0.26 A plus or minus 10% |
| 14 | Pump rating | 3.1W ±10% |
| 15 | Rated pump speed | 2800±10%RPM |
| 16 | Motor type | Three phase brushless sensorless motor |
| 17 | T-rising orTDP | Tests above 250W are for reference only (i9-12900K test bed) and the room temperature is 26° |
| 18 | Bearings | Ceramic |
| 19 | Shaft core | Ceramic |
| 20 | Product life | 30,000 hours, 250 C |
| 21 | Noise | ≤30 dB |
| 22 | Coolant freezing point | -8 °C |
| 23 | Pump power cable | 2510-3P black female,UL2468 26#AWG 3 Parallel, black exposed 300±15mm |
| 24 | LED Screen Power cable | 1061#26AWG quadriplex, quinary, with DuPont2.54_9pin black female end, exposed 400±15mm |
| 25 | ARGB power cable | UL1061#26AWG triple black parallel cable, 300±15/100±15mm leakage, ARBG female end -3P |
| 26 | Control light switch cable | 2.54-2P Dupont male à button, exposedcable length 330mm±10 |
| 27 | ARGB rated voltage | DC12V |
| 28 | ARGB rated current | 0.16 A |
| 29 | ARGB power rating | 1.92 W. |
| 30 | Operating temperature | – 20 ~ 45 ℃ |
| 31 | Storage temperature | – 30 ~ 60 ℃ |
| Fan specifications | |
| Dimensions | 120 x 120 x 25mm |
| Quantity to use | 2 |
| Rated voltage | 12V |
| Rated current | 0.03 0.29 A |
| Noise | < 36.1 dBA |
| ARGB Rated voltage | DC5V |
| ARGB Rated current | 0.37 A |
| ARGB power rating | 1.85 w. |
| Bearings | Hydraulic pressure |
| RPM | 800~1800 RPM±10% |
| Material | PBT fan frame, PC fan blade |
| Connecting wire | 2510-4PIN female end, UL1061 #26AWG black parallel wire, wire length 300±10mm |
| ARGB connect wire | 5V/3PIN RGB female end, UL1061#26AWG black parallel wire, 300± 10mm wire length |
| Part name | Specifications and parameters | Quantity QTY |
| INTEL plastic backboard | INTEL triple-purpose plastic back plate | 1 |
| INTEL stand | Manganese steel 1.5mm thick, electrophoretic black | 2 |
| AMD holder | Manganese steel 1.5mm thick, electrophoretic black | 2 |
| Fan Screw | Fanscrew 6-32X29.0mm | 8 |
| Radiator screw | Water screw 6-32X6mm | 8 |
| Bracket screws | M3X6mm, cross countersunk, electroplated black nickel | 4 |
| INTEL 115X 1700 1366 screw | Easy iron, nickel-plated surface, cross round head | 4 |
| INTEL 2011 screw | Easy iron, nickel-plated surface, cross round head | 4 |
| AMD screw | Easy iron, nickel-plated surface, cross round head | 4 |
| Spring | Wire diameter 1.0mm, piano wire | 4 |
| Thermal grease | 0.5g gram | 1 |
| Fan adapter cables | One belt two fan connector | 1 |
| Instructions | Instructions | 1 |
| Instructions Packing | |
| Net weight of product | 0.80 KG |
| Gross weight of product | 1.46 KG |
| Packing method | color box + outer box |
| Outer box size (6 packs) | 60*400*290MM (Estimated) |
| Shelf life | |
| Shelf life (1 year) | 1 year |
| Applicable mounting platform | |
| Intel Platform: | 115X/1700/2011/2066 |
| AMD platforms: | AM2/AM3/AM4/AM5 |
